Lights: System: 12 volt ICC with 7-way connector and wiring harness. Two groups of two individual red STOP and TURN tail lights are factory sealed. Resealable clearance lights have Lexan turtle-back lenses, lights are 2-bulb replaceable. Combination center marker light and turn signal is standard. Suspension: (Air ride) Turner/Hendrickson HT 230 (Spring Ride) H-9700 fabricated steel, screw adjusted radius rods, and 11,200 Lb. rated three-leaf springs. Axles-Hubs and Drums: Axles: 5" round, rated at 22,500 Lbs.., located 49 1/4" from rear of trailer to center between axles. Hubs: Cast Steel. Drums: Cast steel, outboard mount Oil Seals: Severe service. Brake Linings: EF non-asbestos. Brakes: 16 1/2 x 7" x 5/8", double anchor pin, less dust shields, Wheels: Eight 8.25 x 24.5 white steel disc wheels, optional: alum.wheels polished on the outside. Tires: Eight 11R24.5, Bridgestone R293 or R194 Tarp: Roll tarp with aluminum caps; or drop tarp with rope-lock hooks on curb side and conventional rope hooks on driver's side are extra cost option. Finish: Outside Skin: Pre-painted white on front and rear ends, and sides. Unfinished alum. components left natural. Steel components painted gray. Black outside is available as an option on 66" side height. |
